Pilot Ladder (MED/SOLAS)

Our MED/SOLAS approved pilot ladder is crucial safety equipment in the maritime industry, facilitating the safe and efficient transfer of pilots to and from ships while meeting strict safety standards.

Lengths available from 2m to 22m, select bottom structure Open End Type or Closed End Type.



Product Features:
  • MED/SOLAS approved, met the required standards (ISO 799-1:2019).
  • Used every day by maritime pilots around the world to board and disembark ships.
  • Steps have non-skid surfaces, secured with sea water resistant aluminium clamps.
  • Ropes are not painted, coated or covered, thimbles will be provided.
  • Ropes are spliced to top on the ladder.
  • All steps are made from hardwood, only bottom 4 steps are made from rubber.
  • All ladders are digitally stamped, by scanning the QR code on the ladder’s certificate tag located below the top step and the lowest spreader, marine pilots can verify the ladder’s authenticity, view the vessel name and access digital copies of all compliance certificates in real time.
Technical Specifications
Model DMSE-PL
Rope Manila Rope (Ø20)
Fastening Clip Aluminium
Plastic Insert Polypropylene
Hook Galvanized Carbon Steel
Regular Step Hardwood (525mm X 115mm X 28mm)
Spreader Step Hardwood (1800mm X 115mm X 28mm)
Bottom 4 Steps Rubber (525mm X 115mm X 40mm)
Distance between each adjacent steps 330±20mm
Approval DNV, RINA
Testing Standards IMO Res.A.1045(27), as amended; ISO 799-1:2019
Reference Standards Reg. V/23 and Reg. X/3 of SOLAS 74 Convention as amended; IMO Res.A.1045(27), IMO MSC/Circ.1428
Number Of Steps On Ladder/Positions Of Spreader Steps
Ladder Length(m) Number Of Steps Positions Of Spreader Steps
2 7 5
3 10 5
4 13 5
5 16 5, 14
6 19 5, 14
7 22 5, 14
8 25 5, 14, 23
9 28 5, 14, 23
10 31 5, 14, 23
11 34 5, 14, 23, 32
12 37 5, 14, 23, 32
13 40 5, 14, 23, 32
14 43 5, 14, 23, 32, 41
15 46 5, 14, 23, 32, 41
16 49 5, 14, 23, 32, 41
17 52 5, 14, 23, 32, 41, 50
18 55 5, 14, 23, 32, 41, 50
19 58 5, 14, 23, 32, 41, 50
20 61 5, 14, 23, 32, 41, 59
21 64 5, 14, 23, 32, 41, 59
22 67 5, 14, 23, 32, 41, 59
Pilot Ladder DMSE-PLTechnical Data sheetpdf - 3 MBDownload
