Aluminium Wharf Ladder (Flat Type)

An essential safety platform that provides stable and secure access for personnel and cargo when the ship is moored next to a dock. The set includes removable aluminium handrails and ropes that can be installed as needed.

Contact :

Length available in 2m, 2.5m, 3m, 3.5m, 4m, 5m, and 6m

Length	Safe Working Load
2m	143kg
2.5m	210kg
3m	210kg
3.5m	240kg
4m	240kg
5m	360kg
6m	420kg

Product Features:

ABS approved safety platform that provides stable and secure access for personnel and cargo when the ship is moored next to a dock.
Clear width of 60cm allows for safe and easy access for individuals.
Cross ridges for foot support with non-slip walking surface.
Designed with rollers and hook for easy mounting.
The set includes removable aluminium handrails and ropes that can be installed as needed.

Technical Specifications

Model	HXTB-P
Material	Aluminium
Approval	ABS test report
Inspection Standards	The safe working load test was performed within the specified inspection scope and witnessed by ABS technical representative. The results were found to be satisfactory according to the supplier’s test procedure (No.: HXTB002 Rev: 002). Detailed technical requirements are outlined in the test report.

Aluminium Wharf Ladder (Flat Type)

Technical Data Sheet

pdf - 625 KB
